Calix E7-2 User Manual

168
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Parameters when managing configuration files
Parameter Description
Source FTP Server* The IP address of your FTP server.
Source User* Username required by your FTP server.
Source Password* Password required by your FTP server.
Source File Path* File path of the configuration file on your FTP server.
Config Name* A configuration name instance is mapped to a retrieved DSL Configuration file, whose
contents will be applied to all DSL ports on the VDSL2 card.
Each VDSL2 card supports 2 VoIP configuration files (1 applied and 1 not-applied) for a
total of 4 VoIP configuration files per system.
The configuration name specified in the Retrieve/Apply DSL Configuration File operation
must match the configuration file instance specified in the IP Host. A configuration name
is specified by instance number alone or by “voip-<1 through 4>.”
 voip-1 - Instance for VOIP (1)
 voip-2 - Instance for VOIP (2)
 voip-3 - Instance for VOIP (3)

voip-4 - Instance for VOIP (4)
Version* The version number of the DSL configuration file <x.x.x.x>. Typically, the version string is
the first line in the configuration file.
Note: The VDSL2 card will not download a new configuration file, unless the version
number in the file is different from what is in the file currently applied.
Force Select the Force box to force the system to retrieve and name the file as specified.
*Required field
To manage configuration files
1. On the Navigation Tree, click a VDSL2 card.
2. In the Work Area, click DSL Configuration > Action.
3. Select one of the actions, described in the table above:
 Retrieve
 Apply
 Remove
4. Click the appropriate confirmation to invoke the action.
For CLI:
retrieve dsl-config
apply dsl-config
remove dsl-config
cancel dsl-config
reset card
