Proprietary*Information:*Not*for*use*or*disclosure*except*by*written*agreement*with*Calix.*
"!#$%&'(!)%%!*&+,-.!*/./01/2(!
:A! Connect the chassis ground cable to the main ground system (preferred) or to the rack
a.! Route the ground cable to the grounding termination location. If the cable is too
long, cut the cable to length and crimp on an appropriate lug. (A spare lug is included
in the installation kit.)
b.! Connect the ground cable to the main ground system or rack frame per PANI
Note: When grounding to a rack frame, ensure that there is no paint or debris between
the ground lug and the rack frame. To ensure a reliable ground bond, apply an anti-
oxidant and use paint piercing star washers and thread forming screws to secure a metal-
to-metal ground contact to the rack frame.
<A! Power, ground, and alarm wiring at the rear of the E7-20 must be properly secured with
