Proprietary*Information:*Not*for*use*or*disclosure*except*by*written*agreement*with*Calix.*
"!#$%&'(!)%%!*&+,-.!*/./01/2(!
The Calix E7-20 ground system can be connected to a Common Bonding Network (CBN) or
Isolated Bonding Network (IBN).
Note: For environments that employ an IBN scheme, the low voltage and frame grounds on
the E7-20 shelf are isolated from the input power DC-return.
The installation kit includes a 12-foot ground cable, plus hardware to attach it to the E7-20
frame ground. The grounding terminal for anti-static wrist strap connection is located on the
left side of the chassis.
'PM!BZ'?C\!!E/O$0/!4C!/%/6-04.-$-&6!2&.6,$0+/(!J4%%4O!.-$52$02!7<L!
M0/6$D-&45.(!)%O$Q.!O/$0!$!+04D52/2!7<L!O0&.-@$52!-4!$14&2!2$9$+&5+!-,/!
/%/6-045&6!/RD&M9/5-(!
H4!+04D52!-,/!7F=>I!6,$..&.!
9A! Get the ground cable and supplied hardware (pair of 10-32 Keps nuts and washers) from
*A! Connect the ground cable to the E7-20 chassis as follows:
a.! Install (2) star washers and then the ground cable's 2-hole lug onto the dual-post
Frame Ground terminal (located on the rear of the chassis).
b.! Install (2) 10-32 Keps nuts onto the Frame Ground posts to secure the lug in place.
Tighten to 27 in-lbs of torque.
