Installing+the+Fa n+T ra y +A ssembly+
Install the E7-20 Fan Tray Assembly (FTA) and air filter into the E7-20 chassis as described
below.
C0!%-./#$$!/D4!'()*+!Q#-!N032$4!#-3!#%7!Q%$/47!
9A! Unpack the E7-20 fan tray assembly from its packaging.
*A! Insert the fan tray assembly into the housing just below the E7-20 chassis, aligning the
rails.
:A! Push the fan module all the way back into the chassis. The unit seats once the latches
click into place.
<A! Grasp the two embossed tabs on the sheet metal door, just below the fan tray latches,
and then pull back to open the door.
