"!#$%&'(!)%%!*&+,-.!*/./01/2(!
EA! Insert the air filter into the chassis:
a.! Orient the air filter where the direction of the arrow stamped into the metal frame is
pointing upward.
b.! Align the filter on the rails, and then push it back into the chassis.
OA! Close the fan-filter door.
