2.0 INSTALLATION
UNPACKING
CONTROL CONSOLE
%
REMOVABLE
PANEL
CONSOLE
DUCT
CONTROL CONSOLE
LPHW FITTED
ºC
%
=
=
= AUTO
CONTROL CONSOLE
CONNECTION POINT
On delivery the console for the AA300 will be inside the machine. To retrieve the console unfasten the removable
panel on the heat pump. The console should be in the position shown, protected by bubblewrap. Note: the
removable panel is on the opposite face of the heat pump to the water connections.
