Page 26
4.0 DATA SHEET
AA300AVH(F)
For accurate application sizing consult CALOREX Heat Pumps Ltd
Boiler not required for AA versions without LPHW.
MODE B = recovered heat biased to pool hall air
R407c Global warming potential (GWP) 1700.
1 mm WG = 9.8pa
1 mhd = 1.4psi
1 L/min = 0.22 gall/min
MODEL:- Units AA300
MINIMUM º C 15
MA XIMUM º C 36
DEHUM IDIFICATION
DUTY
VIA HEAT PUMP (30ºC/60% rh) litres/hr 3.6
VIA HEAT PUMP (MODE B):- kW 4.4
VIA LPHW @ 80ºC :- kW 7.3
TOTAL :- (MODE B) kW 9.8
RECOMMENDED BOILER CA PA CITY kW 7.3
RECOMMENDED BOILER CA PA CITY Btu's /hr 25000
FLOW RA TE l/min 10
Pressure Drop @ Rated Flow m/hd 2.9
Max system w orking pressure bar 6
V/ph/Hz 230V/ ~1N/50Hz
ELECTRICAL
TOTA L POWER CONSUMED (nominal) :- 'F' & NON 'F' kW 2
MIN' SUPPLY CA PA CITY ( Max F.L.A .) A mps 13
MAX' SUPPLY FUSE 1 ph N:- 'F' & NON 'F' Amps 20
AIR FLOW (anemometer @ air on f ilter, w et evaporator) m³/hr 1300 ±10%
MA X EXTERNA L STA TIC PRESSURE: - NON 'F' Pa 95
MA X EXTERNA L STA TIC PRESSURE: - 'F' Pa 11 0
DESIGN CONDITION Amps:-
1 ph N :- NON 'F' Amps 1.04
1 ph N :- 'F' Amps 1.5
FLA:- 1 ph N:- Amps 2.6
NOMINA L POWER CONSUMED:- kW 1.9
LRA:- 1 ph N:- Amps 46
RLA:- 1 ph N:- Amps 8.6
SOFT START Amps 1 ph N:- Amps 24
Hermetic System
GA S CHA RGE ( R407c ) kg 2.6
LPHW battery volume litres 1.15
IP RA TING IP 22
WIDTH (Unpacked) mm 730
DEPTH (Unpacked) mm 1025
HEIGHT (Unpacked) mm 850
WEIGHT approx' (AA un-packed no options):- kg 111
NOISE LEVEL @ 1m dBA 61
GENERAL DAT A
COMPRESSOR
MAIN FAN
PHYSICAL
DIM ENSIONS
HEAT TO AIR
RECOM M ENDED
BOILER CAPACITY
(AA+LPHW)
AIR TEMPERATURE
LIMITS
