Page 24
=
= O
ºC
7 Air heating lamp Indicates that there is a demand for the unit to
heat the pool hall air.
8 Pool hall symbol
9 Manual override symbol
10 Pool water occupied (no pool cover)
11 Pool water unoccupied symbol (pool covered)
The AA 300 with LPHW console has the same basic controls as the standard machine with the following
additional controls:
MODEL WITH LPHW FITTED (12V)
ºC
%
CONSOLE AA300
WHEN FITTED WITH LPHW
AIR TEMPERATURE
DISPLAY AND 7. AIR
HEATING LAMP
TIME
CLOCK
=
=
= AUTO
8. POOL HALL SYMBOL
AUTO SYMBOL
9. MANUAL SYMBOL
10. OCCUPIED SYMBOL
(no pool cover)
11. UNOCCUPIED SYMBOL
(pool covered)
