Calorex Pro-Pac 45 - Data Sheets

AIR TO WATER HEAT PUMPS FOR SWIMMING POOL AND HOT WATER APPLICATIONS.
400V 3N~ 50HZ UNITS (BM)
9.0 DATA SHEETS
model Pro-Pac 30 Pro-Pac 45 Pro-Pac 70 Pro-Pac 90 Pro-Pac 140
UNITS
DUTY
Air On @ 20°C, 65%RH HEATING
Output To Water (@ 26ºC) kW 32 40 62 80 124
Electrical Input kW 7.8 9.75 14.4 19.5 29
ELECTRICAL DATA
Electrical Supply 3 Phase V/ph/Hz |---------------- ---------------- 400V 3N~/50Hz ----------------- ---------------|
Minimum Supply Capacity 3 Phase A 20 22 35 43 67
Recommended Supply Fuse 3 Phase A 30 30 50 60 100
Max Starting Current STD (LRA) A 80 96 174 96 174
Max Starting Current S/Start (LRA) A 31 33 40 33 40
AIR DATA
Nominal Air Flow m
3
/hr 5500 12000 14000 24000 28000
Fan External Resistance mm WG 0 0 0 0 0
Fan External Resistance 'F' mm WG N/A 4.5 6 4.5 6
WATER DATA (PPT Pro-Pacs)
Water Flow ±10% L/min 250 300 500 600 1000
Pressure Drop (Water) m hd 0.7 0.4 1.5 1.4 2.1
Water Connections inches 2" UNION SKT 2” UNION SKT 3" BSPM 3" BSPM 4" BSPM
Condensate Water Connections inches 1½" BSPM 1½" BSPM 1½" BSPM 1½" BSPM X 2 1½” BSPM X 2
PP Pro-PacS
Water Flow ±10% L/min 66 66 133 133 266
Pressure Drop (Water) m hd 2.1 4.2 3.9 4.2 5.3
Water Connections inches 1½" BSPM 1½" BSPM 1½” BSPM 1½” BSPM
2" BSPM
GENERAL DATA
Hermetic System
Gas Charge (R407c) PPT kg 12.5 15.4 18 14 x 2 15 x 2
Carbon dioxide equivalent tonnes 22.2 27.3 31.9 24.8 x 2 26.6 x 2
Gas Charge (R407c) PP kg 8.5 17 - - 29 x 2
Carbon dioxide equivalent tonnes 15.1 30.2 51.4 x 2
Compressor Type SCROLL SCROLL SCROLL 2 x SCROLL 2 x SCROLL
Fan Type AXIAL AXIAL AXIAL 2 x AXIAL 2 x AXIAL
*Sound Pressure Level @3m AIR ON dB(A) 64 65 70 65 70
*Sound Pressure Level @3m AIR OFF dB(A) 60 61 64 64 67
*Sound Pressure Level @3m SIDE dB(A) 61 64 65 61 65
DIMENSION DATA
Wid (unpacked) PPT mm 1585 1695 1840 2095 2250
Wid (unpacked) PP mm 1555 1665 1810 2065 2210
Dep (unpacked) mm 790 1060 1190 1190 1650
Height (unpacked) mm 1080 1330 1310 1350 1340
Weight (unpacked) PPT Pro-Pacs kg 219 330 417 TBA 816
Weight (unpacked) PP Pro-Pacs kg 247 TBA TBA 633 808
Wid (export, packed) mm 1775 1875 2020 2295 2470
Dep (export, packed) mm 900 1170 1300 1310 1770
Height (export, packed) mm 1250 1500 1480 1520 1505
Weight (export, packed) PPT Pro-Pacs kg 240 439 544 TBA 1036
Weight (export packed) PP Pro-Pacs
kg 268 TBA TBA 748 1028
NOTES
(1) Weight and Dimensions Nett.
(2) Allow 500mm clearance to service panels.
(3) Minimum air temperature 7°C.
(4) Water to have correct balance pH 7.2 -7.8. Free Chlorine 1.0-2.0 ppm Domestic, 3.0-6.0 Commercial.
(5) Danerm Ltd. reserve e right to change or modify models wiout prior notice.
(6) R407c Global Warming Potential (GWP) 1774.
*(7) Noise tests performed in accordance wi BS ISO 3744:2010: k factor 0.
33
SD566252 ISSUE 51
