Page 30 / 164 I-MAT_Ed6 - Operating Instructions
The currents of the converter are reported in the
following table.
Inverter Type In (A)
I-MAT 5,2TT-A 5.2
I-MAT 11,2TT-B 11.2
I-MAT 25,8TT-C 25.8
I-MAT 65,4TT-D 65.4
I-MAT 119TT-E 119
Input Power Data
Unity Power Factor (Cos φ) >0.98
Real Power Factor (Lambda) >0.9
Type of power supply systems: TN and IT networks.
Switching on feed lines (L1, L2, L3): 2 times/min
Harmonic disturbance in accordance with:
- EN61000-3-2 for converters with nominal current
up to 16 A.
- EN61000-3-12 for converters with nominal current
greater than 16 A
EMC lter on board:
- C1 class B integrated up to 11kW
- C2 class A-Group 1 from 15 kW thin to 55kW
Output Power data (U, V, W)
Output voltage: 0-95% of the supply voltage in the
standard version.
Modulation Frequency PWM: da 2 kHz a 8 kHz.
dV/dt of the output phases: MAX 5kV/us
Digital inputs
5 Opto-insulated inputs:
- 2 entrances lack water
- 1 Input Enable minimum maximum curve/curve
- 1 Input Enable secondary set point
- 1 Input Enable /disable remotely
ON level: 18-30V
OFF level: 0-3 V
Maximum input voltage: 30V DC
Entrance Resistance, Ri: ~2kohm.
Scan time: 1 ms.
Analog inputs:
Analog inputs: 2 inputs differentially:
- Primary sensor
- Secondary sensor
Mode: Voltage (0-10V) or Current (0/4-20 mA).
Input impedance: Current mode 500 Ohm
Tension mode: 60 kohm.
Analog Revenue Accuracy: Max error 1% of the
11-bit-sign 11-bit-disk fund.
Scan time: 1 ms.
Analog output:
Analog output eld: 0/4-20 mA.
Maximum load to be piloted: 500 ohm.
Analog Output Precision: Max error 2% bottom
scale.
D.C. Power:
Internal power supply: 24V -10%
Maximum applicable load:
150 mA available for each output up to max 0.5 A
total cc (short circuit protection and overhead).
Relay output:
Programmable outputs: 2 Relay, third optional relay
in multi-ash card.
Alarm signaling, or for start/stop pump signaling
Maximum resistant load:240VAC 200 mA, 30 VDC
2 Ampere
Applicable voltage: 0-30 VDC
0-220 VAC
3.3. Operating conditions
The product works properly only if the followings
conditions are respected.
- Floating voltage rate: +/-2% max
- Floating frequency rate: 50-60 Hz +/-2%
- Ambient temperature: -10°C a +50°C
- Relative Humidity: from 20 to 90% without
condensing
- Vibration: max 16,7 m/s2 (2 g) at 10-55Hz
- Altitude: Below 1000 m inside a building.
- Galvanic isolation (I/O feeds according to
PELV)
The current of the frequency converter must be
equal or greater than the maximum current that the
motor of the pump could absorb.
The system is made of:
Frequency converter
Transducer (pressure/temperature/ow are
possible)
Mounting Screws
Motor Adapter Kit
3.4. Product overview
I-MAT is a frequency converter for pumps, that
implements the followings operating modes:
Constant pressure;
Proportional pressure;
Constant temperature;
Constant ow;
Night mode;
Fixed speed;
Constant pressure mode and Proportional pressure
mode are available also in cascade mode.
3.5. Pushbuttons functions
The user interface is made by a 6 pushbuttons
keyboard. Every pushbutton has a specic function
described in the following table.
Through this button you can start the
pump.
Through this button you can stop the
pump
