Page 52 / 164 I-MAT_Ed6 - Operating Instructions
19. Accessories
19.1. Filters for the reduction of irradiated noise and electromagnetic noise emissions
I-MAT Inom (A) Filter Max Cable lenght Sinusoidal lter Max Cable lenght
I-MAT 5.2TT-A
0.1 - 2
CNW 854/8
150 m
CNW 933/6
600 m
2 - 4
4 – 5.2
I-MAT 11.2TT-B
5.3 - 6
6 - 8
CNW 933/8
8 - 10 CNW 854/10 CNW 933/10
10 – 11.2
CNW 854/12 CNW 933/12
I-MAT 25.8TT-C
11.3 - 12
12 - 16 CNW 854/16 CNW 933/16
16 - 20
CNW 854/24
CNW 933/20
20 - 24 CNW 933/24
24 - 25,8 CNW 854/30 CNW 933/30
I-MAT 65,4TT-D
25,9 - 30 CNW 854/30 CNW 933/30
30 – 37 CNW 854/37 CNW 933/37
37 - 48 CNW 854/48 CNW 933/48
48 – 60 CNW 854/60 CNW 933/60
60 – 65,4 CNW 854/75 CNW 933/75
I-MAT 119TT-E
65,4 – 75 CNW 854/75 CNW 933/75
75 – 90 CNW 854/90 CNW 933/90
90 – 115 CNW 854/115 CNW 933/115
> 115 CNW 854/150 CNW 933/200
19.2. Capacitor Kit
Capacitor Kit Dimensions (LxHxP) Mounting
Capacitor Kit for I-MAT 5,2TT-A 155x210x73.5 mm Wall Mounted
Capacitor Kit for I-MAT 11,2TT-B 167x210x73.5 mm Wall Mounted
Capacitor Kit for I-MAT 25,8TT-C 238x277x83.5 mm Wall Mounted
For higher power sizes, contact the manufacturer
19.3. Optional cards
Board Type Position Function
Board Cascade mode VV Internal, Slot 3 RS485 for multipump VV
Board Cascade mode VV+VF Internal, Slot 3 RS485 for multipump VV
5 relays for multipump VV+VF
Modbus Board External, Slot 1 Modbus
19.4. Connectors
Connector Type Function
M12 Male 5 poles A-code HMI remoting
M12 Female 5 poles A-code HMI remoting
M12 Male 5 poles B-code Modbus connection
M12 Female 5 poles B-code Modbus connection
