16.1. Parameters UP – user parameters
N° Description Values Standard Modication
UP01 Restart mode power failure
rA = automatic
rM = manual
rA
UP02 Nominal pump current (A) s.m.
UP03 Nominal pump frequency (Hz) 50
UP04 Direction of rotation E---
UP05 Operating mode
PC = Constant pressure
PP = Proportional pressure
tC = Constant temperature
CF = Constant ow rate
Man = Fixed speed
PC
UP06 Primary set-point 1,5
UP07 Secondary set-point 1,5
16.2. Parameter AP – Advanced parameters
N° Description Values Standard Modication
AP01 Maximum pump pressure (bar) 0
AP02 Primary transducer supply
1 = 0-10V
2 = 4-20mA
3 = 0-20mA
2
AP03 Primary transducer measuring unit
1 = bar
2 = m3/h
3 = Hz
4 = °C
1
AP04 Primary transducer minimum value 0
AP05 Primary transducer maximum value 10
AP06 Secondary transducer supply
1 = 0-10V
2 = 4-20mA
3 = 0-20mA
2
AP07 Secondary transducer measuring unit
1 = bar
2 = m3/h
3 = Hz
4 = °C
1
AP08 Secondary transducer minimum value 0
AP09 Secondary transducer maximum value 10
AP10 Secondary transducer mode
Off
DiFF = Differential mode
nMOd = Night mode
REM = Remote control
Off
AP11 Cascade mode
Off
UU = Cascade 2-6 converters
UF = Single converter
cascade
dP = Twin pump
Off
AP12 Master/Slave setting
MAS = master
SLA = slave
SLA
AP13 Pump address SLA1÷SLA5 SLA1
AP14 Rump-up (s) 3
AP15 Rump down (s) 3
AP16 Stand-by mode setting
Off
FM = minimum frequency
PrP = pre-pause frequency
Off
AP17
Frequency before stop and minimum run
frequency automatic calculation
Auto = automatic
Man = manual
Auto
AP18 Night mode enable On, Off Off
AP19 Night mode activation (°C) 20
AP20 Night mode activation time (min) 60
AP21 Night mode disable threshold (°C) 20
AP22 Dry-run time (s) 10
AP23 First dry-run time (s) 60
AP24 Dry-run pressure (bar) 1,5
AP25 Periodically start system activation time (Ore) 0
AP26 Periodically start system frequency (Hz) 40
AP27 Periodically start system operating time (min) 1
AP28 System leakage control On,Off Off
