Cambium Networks PTP 820C Installation Guide

Chapter 6: Installation Procedures per Configuration Type
4+0 Dual Polarization, 2+2HSB Single/Dual
Polarization Direct Mount
phn-3962 004v000
Page 6-71
4+0 Dual Polarization, 2+2HSB Single/Dual
Polarization Direct Mount
List of Items
Table 52 Required items for 4+0 Dual Polarization, 2+2 HSB Single/Dual Polarization Direct Mount
Item
Description
Quantity
Remarks
1
PTP 820C Dual
Coupler/Splitter/Circulator
1
2
PTP 820C OMT/Splitter Kit
1
3
PTP 820C Radios
2
Required Tools
• Metric offset hexagon key set
• Metric wrench key set
Procedure
173B1
Once the OMT/Splitter is mounted to the antenna, connect the PTP 820C Dual Coupler/Splitter kit to
the OMT kit using four M8 screws and washers, and tighten the screws.
Caution
Verify that the O-ring is properly mounted between the OMT/Splitter ports and the
Dual Coupler/Splitter.
