Cambium Networks PTP 820C Installation Guide

Chapter 6: Installation Procedures per Configuration Type
2 x MultiCore 2+0 Dual Polarization Direct
Mount
phn-3962 004v000
Page 6-44
2 x MultiCore 2+0 Dual Polarization Direct Mount
Figure 23 2 x MultiCore 2+0 Dual Polarization Direct Mount
Note
This procedure can also be used for MultiCore 2+0 DP HW ready for 2 x MultiCore 2+0
DP configurations.
List of Items
Table 40 Required items for 2 x MultiCore 2+0 Dual Polarization Direct Mount
Item
Description
Quantity
Remarks
1
PTP 820C RADIO
2
2
PTP 820C OMT KIT
1
3
PTP 820C DUAL COUPLER or
SPLITTER KIT
1
4
CIRC./CIRC. ADAPTOR
1
Per Antenna Vendor
Required Tools
• Metric offset hexagon key set
• Metric wrench key set
