Cambridge Audio Edge NQ Instructions

10
Technical specications
D/A Converters ESS ES9018K2M
THD @ 1kHz 0dBFs <0.001% 24-bit
THD @ 1kHz -10dBFs <0.001%
THD @ 20kHz 0dBFs <0.002%
Frequency Response 20Hz-20kHz +/- 0.1dB *
S/N ratio(ref 1W into 8 Ohm) >88 dB
S/N ratio (ref full power) >103 dB
Total correlated jitter < 130pS
Crosstalk @ 1kHz < -100dB
Crosstalk @ 20kHz < -90dB
Audio Formats WAV containing uncompressed
PCM 16-24 bit 32-192kHz
FLAC containing losslessly
compressed
PCM 16-24 bit 32-192kHz
Apple Lossless (ALAC) containing
losslessly compressed
PCM 16-24 bit 32-192kHz
AIFF containing uncompressed
PCM 16-24 bit 32-192kHz
Microsoft® Windows Media
TM
Audio (WMA 9 Standard) 32-
320kbps
MP3 (CBR or VBR) 16-320kbps
AAC, HE AAC and AAC+
(CBR or VBR) 16-320kbps
OGG Vorbis 32-320kbps
DSF and DFF containing DSD64 at
2.8224 MHz or DSD128 at 5.6448
MHz
Streaming Protocols RTSP (Real Time Streaming
Protocol)
MMS (Microsoft Media Server
Protocol)
HTTP (Hyper Text Transfer
Protocol)
Playlist ASX (Microsoft® playlist format)
M3U, PLS
Wi-Fi IEEE 802.11 b/g or n (2.4GHz
connection used only)
Wi-Fi Encryption WEP, WPA, WPA2
Ethernet IEEE 802.3, 10 Base-T or 100
Base-T
USB 1 x USB 1.1 current limited to 1A
USB audio input USB Audio prole 2.0
Compatibility USB 2.0: Up to 32-bit 384kHz
TOSLINK: 16/24-bit 32-96kHz
Coax SPDIF: 16/24-bit 32-192kHz
File systems FAT32, NTFS
Standby consumption <0.5W
Max power consumption 100W
Dimensions 120 x 460 x 405mm
(4.7 x 18.1 x 15.9")
Weight 17kg (37.4lbs)
* iRadio/Streaming Services are output as 16-bit data at the
appropriate sample rate for the decompressed data. The sample rate
will be 32kHz, 44.1kHz or 48kHz depending on the streams sample
rate.
Incoming streams of less than 32kHz sample rate cannot be output
over S/P DIF /TOSLINK.
For compressed streams the true resolution of the audio is of course
limited by the encoding.
For Media content from local drives or UPnP this outputs in its native
resolution of 16/24-bit, 32kHz, 44.1kHz, 48kHz, 96kHz, 88.2kHz,
176.4kHZ and 192kHz with bit for bit transfer.
(Audio les over
Ethernet, Wi-Fi or
attached USB storage
device)

Cambridge Audio Edge NQ Specifications

General

Type	Network Player / Preamplifier
DAC	ESS Sabre ES9018K2M
Maximum Resolution Supported	32-bit/384kHz PCM, DSD256
Ethernet	Yes
Weight	10.2 kg (22.5 lbs)
Inputs	2x Coax S/PDIF, 2x TOSLINK Optical, 1x USB Audio, 1x XLR
Outputs	1x RCA, 1x XLR, 1x Coaxial S/PDIF, 1x TOSLINK Optical
Streaming Services	Chromecast, Spotify Connect, TIDAL, Qobuz, AirPlay, Internet Radio
File Formats Supported	FLAC, ALAC, WAV, AIFF, MP3, AAC, WMA, OGG, DSD
Wi-Fi	Yes (802.11 b/g/n/ac)
Bluetooth	Yes, aptX HD
USB Audio Input	Yes
Headphone Output	Yes, 6.3mm jack
Dimensions	120 x 460 x 405mm (4.7" x 18.1" x 15.9")
