Camco iD4 - Page 25

USER MANUAL
i -SERIES
i-SERIES
advancEd amplIfIERS
P. 25
20 100 1k 10k 20k
Hz
Ω
300 m
100 m
10 m
2 m
20k10k1k10010
Hz
1000
800
600
400
200
0
damping factor
7 TYPICAL PERFORMANCE DIAGRAMS
Figure 7.9
Output impedance vs. frequency
@1AmpRMSinjectedcurrentequivalent11mΩ+2,1µH
(Measurement of a typical performance of Ch 1 & Ch 2)
Figure 7.10
Dampingfactorinto8Ω
(equation: damping factor = loaded impedance / amplifier output impedance)
(Measurement of a typical performance of Ch 1 & Ch 2)
