6 09/2014
© CAME cancelli automatici S.p.A. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici S.p.A. to notify users.
ENGLISH
4.1 Gearmotor
This product is engineered and built by CAME cancelli automatici S.p.A. in compliance with applicable safety standards.
The electro-lock fitted (A3000/A3006/A5000/A5006) irreversible or (A3100/A31006/A5100/5106) reversible gearmotor, is made up
of two cast-aluminium half shells containing a gearmotor with epicycloid gearbox system.
A double, electromechanical limit-switch system is fitted above the gate-movement worm-screw
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you what to say to the end-users.
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
2 Intended use and restrictions
The ATI 230V gearmotor is designed to power residential and condominium swing gates.
Any use, other than that described above or installations performed in ways other than those described herein, are forbidden.
3 Reference Standards
2.2 Restrictions
4.2 Technical features
For its quality processes management Came Cancelli Automatici is ISO 9001 certified, and for its environmental management it
is ISO 14001 certified.
This product complies with the following standards: see declaration of conformity.
Gate leaf
width
m
Gate leaf weight
kg
A3000-A3006-A3100-A3106 A5000-A5006-A5100-A5106
2.00 800 1000
2.50 600 800
3.00 400 600
4.00 / 500
5.00 / 400
Motor power supply: 230V A.C. 50/60Hz
Max draw.: 1,2A
Power: 150W
Opening time (90°):
A3000 / A3100 = 19 s
A3006 / A3106 = 28 s
A5000 / A5100 = 32 s
A5006 / A5106 = 45 s
Gear ratio: 1/36
Thrust: 400 ÷ 3000N
Duty cycle: 50%
Condenser: 10μF
Protection rating: IP44
Weight:
A3000 / A3100 / A3006 / A3106 = 10 kg
A5000 / A5100 / A5006 / A5106 = 11 kg
With swing gates it is always advisable to install and electro-lock. This is to ensure a reliable closing and to protect the gearmo-
tor’s inner workings.
But whereas with reversible operators it is merely advisable, with irreversible ones, beyond 4 m, it is obligatory.
