6 09/2014 © CAME cancelli automatici S.p.A. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici S.p.A. to notify users.
ENGLISH
5.7 Adjusting opening STOP microswitch
Spindle
Endless screw
Microswitch bar
Release the gearmotor and set the gate leaf to the full opening position required.
Slide the microswitch unit on the microswitch sled until the same is inserted by making contact with the microswitch actuating sled.
Secure the microswitch unit with the screws.
Microswitch unit
Microswitch actuating sled
Microswitch
5.6 Release with customised key
Only for: A3000/A3006
A5000/A5006
Key
Door
Screw
Release only with motor stopped:
1) raise the door;
2) insert and turn key which immediately releases door;
3) manually push or pull gate leaf.
To lock gate leaf again into place just insert key again and turn.
