Page 10 - Manual FA01810-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Cable types and minimum thicknesses
Cable length (m) up to 20 from 20 to 30
Power supply 230 V AC 3G x 1.5 mm² 3G x 2.5 mm²
Motor power supply 230 V AC 4G x 1.5 mm² 4G x 2.5 mm²
When operating at 230 V and outdoors, use H05RN-F cables compliant with 60245 IEC 57 (IEC); when indoors, use
H05VV-F cables compliant with 60227 IEC 53 (IEC). For power supplies up to 48 V, use FROR 20-22 II cables compliant
with standard EN 50267-2-1 (CEI).
If the cable lengths di er from those specifi ed in the table, defi ne the cable cross-sections according to the actual
power draw of the connected devices and in line with regulation CEI EN 60204-1.
For multiple, sequential loads along the same line, recalculate the values in the table according to the actual power
draw and distances. For information on connecting products not covered in this manual, please see the documentation
accompanying the products themselves.
