Page 11 - Manual FA01810-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
INSTALLATION
The following illustrations are examples only. The space available for fi tting the operator and accessories varies
depending on the area where it is installed. It is up to the installer to fi nd the most suitable solution.
The drawings refer to a gearmotor installed on the left-hand side.
Preliminary operations
Prepare the junction boxes and corrugated tubes you need for the connections from the junction pit.
The number of tubes depends on the type of system and the accessories that are going to be fi tted.

CAME A3000 Specifications

General

Max Gate Weight	800 kg
Power Supply	230 V AC
Motor Voltage	230 V AC
Thrust	3000 N
Intermittence Factor	30%
Operating Temperature	-20°C to +55°C
Protection Level	IP54
Voltage	230 V
Safety Features	Obstacle detection
