Page 15 - Manual FA01810-EN - 06/2022 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Fastening the gearmotor
Unscrew the two screws and remove the casing.
Unscrew the two screws and remove the shaft.
Fasten the gearmotor to the two brackets.
M8x10
M8x50
Lubricate the endless screw and bushing well using a neutral grease.
