CAME BIANCA-C User Manual

Bianca
2
2
1
110
170
31
60
60
83.5
1
2
5
3
6
7
1
2
4
EN
General warnings
• Readtheinstructionscarefullybeforestartinginstallationandproceedasspeciedbythemanufacturer;
• Afterremovingthepackaging,checktheconditionoftheunit;
• Thepackagingitems(plasticbags,polystyrenefoametc.)mustnotbehandledbychildrenastheymaybedangerous;
• Installation,programming,commissioningandmaintenanceoftheproductmustonlybeperformedbyqualiedtechnicianswhohavebeenproperly
trainedincompliancewithcurrentstandards,includinghealthandsafetyregulations;
• Operateinsucientlylitareasthatareconducivetohealthandusetools,utensilsandequipmentthatareingoodworkingorder;
• ThedevicemustbeinstalledinaccordancewiththeIPdegreeindicatedinthetechnicalfeatures;
• Theelectricalsystemmustcomplywithcurrentstandardsinthecountryofinstallation;
• Wiresbelongingtocablesthatarenotusedmustbeinsulated.
• Weldthejointsandtheendsofthewirestopreventmalfunctionscausedbywireoxidation;
• Wheninstallationiscompleted,alwayscheckforcorrectoperationoftheunitandthesystemasawhole;
• Beforeperforminganycleaningormaintenanceoperation,disconnectthepowersupplytothedevice;
• Inthecaseofdevicefailureormalfunction,disconnectitfromthepowersupplyanddonottamperwithit;
• Shouldtheunitbeinneedofrepair,contactonlyatechnicalsupportcentreauthorisedbythemanufacturerandalwaysusesparepartsprovidedbyCAME
S.p.A.
• Theunitmustonlybeusedforthepurposeforwhichitwasexplicitlydesigned.
• Failuretofollowtheinstructionsprovidedabovemaycompromisetheunit’ssafety.
• Themanufacturerdeclinesallliabilityforanydamageasaresultofimproper,incorrectorunreasonableuse.
Disposal
Donotlittertheenvironmentwithpackingmaterial:makesureitisdisposedofaccordingtotheregulationsinforceinthecountrywheretheproductisused.
Whentheequipmentreachestheendofitslifecycle,takemeasurestoensureitisnotdiscardedintheenvironment.Theequipmentmustbedisposedofin
compliancewiththeregulationsinforce,recyclingitscomponentpartswhereverpossible.Componentsthatqualifyasrecyclablewastefeaturetherelevant
symbolandthematerial’sabbreviation.
Installation
Removetheunitfromtheplasticsupportbyslidingitafterpressingtheplasticbutton(gure1).
Fastentheplasticsupporttotheroundbuilt-inboxofØ60mm(gure2)ortotherectangularbox503
(gure3)ortothewall(gure4),usingtheprovidedscrewsandobservingtheUPindication .
Theboxmustbettedatasuitableheightinrelationtotheinstaller.
Avoidexcessivetighteningofthescrews.
Oncetheconnectionshavebeenmade,attachtheterminaltotheplasticsupport(gure5-6).
Toreleasetheunitfromtheplasticsupport,presstheplastichookandlifttheterminal(gure7).
Technical features
Absorption:80mAmax(<1mAstand-by)
Single LED absorption (ring disabled):1mA
Dimensions:110x170x31mm
Storage temperature:-25°C+70°C
Operating temperature:0°C+35°C
IP degree:IP20
