CAME BKV15AGS

10 11 E E3 5
10-E 10-E3 10-5
LN
10 11 E E3 5
+
-
p. 20 - Manual FA01274-EN - 11/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. Original instructions
Signaling devices
(10-E) Flashing light connection output (Contact rated at: 24 V AC/DC - 3 W max).
(10-E3) Additional light connection output (contact rated at: 24 V AC/DC - 12 W max).
(10-5) Gate state warning output (contact rated for 24 V AC/DC - 3 W max.).
Input voltage
(L-N) Line voltage input at 120 / 230 V AC (1P+N+PE) - 50/60 Hz.
(10-11)
Accessories power supply output 24 V AC/DC, max 20 W.
