CAME BX-74 User Manual

#
#
p.
3
- Manual code:
FA00127-EN
FA00127-EN v.
1
- 05/2015 - © Came S.p.A. - The manual's contents may be edited at any time without notice.
4.1 Operator
This product is engineered and manufactured by CAME S.p.A. in compliance with current safety standards.
The operator is made of a cast aluminium part inside of which operates the irreversible, electromechanical gearmotor and an ABS plastic
lining which holds the electronic card and transformer
Important! Check that the command, safety equipment and accessories are CAME originals; this guarantees and make the installation
easy to operate and maintain.
4 Description
2.1 Intended use
2 Conditions of use
The BX-74 motor is designed to operate residential sliding gates; while, the BX-78 may also be used in condominiums.
Do not install or use unless as otherwise shown in this manual.
3 Reference standards
2.2 Limitations to use
BX-74: max weight of the gate is 400 kg.
BX-78: max weight of the gate is 800 kg; for condominium use it is 600 kg.
The company CAME cancelli automatici is ISO 9001 quality certified; it has also obtained the ISO 14001 environmental safeguarding
certification. CAME engineers and manufactures all of its products in Italy.
This product complies with the following legislation: see declaration of compliance.
4.2 Technical features
BX-74 OPERATOR
Control panel power supply: 230V AC 50/60Hz
Operator power supply: 230V AC 50/60Hz
Draw max.: 2,6A
Power: 200W
Max Torque: 24 Nm
Reduction ratio: 1/33
Thrust: 300 N
Max speed: 10 m/min
Operative intermittence: 30%
Protection rating: IP54
Insulation class: I
Weight: 15 kg
Capacitor: 12 μF
Engine thermoprotection: 150° C
BX-78 OPERATOR
Control panel power supply: 230V AC 50/60Hz
Operator power supply: 230V AC 50/60Hz
Draw max.: 2,4A
Power: 300W
Max Torque: 32 Nm
Reduction ratio: 1/33
Thrust: 800 N
Max speed: 10 m/min
Operative intermittence: 30%
Protection rating: IP54
Insulation class: I
Weight: 15 kg
Capacitor: 20 μF
Engine thermoprotection: 150° C
1 Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.

CAME BX-74 Specifications

General

Operating Temperature	-20°C to +55°C
Motor Voltage	230 V AC
Power Supply	230V AC
Safety Features	Obstacle detection
Remote Control	Yes
Manual Operation	Yes
