Page 21 - Manual code: 119DW01EN vers. 5 2016/05 © CAME S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.A.
F1 Total stop function (1-2)
F2 Function associated with the 2-CX input
F3 Function associated with the 2-CY input
F5 Safety test function
F6 Hold-to-run function
F7 Command mode on 2-7
F8 Command mode on 2-3p
F9 Obstacle detection with motor at standstill function
F10 Indicator lamp function
F11 Encoder disabled
F14 Sensor type selection function
F16 Water hammer function
F18 Additional lamp function
F19 Automatic closing time
F20 Automatic closing time after partial opening
F21 Pre-flashing time
F22 Working time
F23 Delayed opening time
F24 Delayed closing time
F28 Motor speed adjustment
F30 Motor slowdown speed adjustment
F34 Sensitivity during movement
F35 Sensitivity during slowdown
F36 Partial opening adjustment
F37 Initial slowdown point adjustment during motor opening
F38 Initial slowdown point adjustment during motor closing
F39 Initial approach point adjustment during motor opening
F40 Initial approach point adjustment during motor closing
F46 Setting number of motors
F50 Saving data in the memory roll
F51 Reading data from the memory roll
F59 Enabling CAME logo function
F60 Sleep Mode function
U1 Adding a new user with associated command
U2 Deleting a single user
U3 Deleting all users
A2 Motor test
A3 Run calibration
A4 Reset parameters
H1 Software version
Menu mapping
Important! Start programming, performing these operations first:
1 Motor test;
2 Run calibration.
A2 Motor test 0 = Disabled / 1 = Enabled
Check the operation of the gearmotor and the correct direction of rotation(see motor test paragraph)
A3 Run calibration 0 = Disabled / 1 = Enabled
Automatic gate run calibration (see run calibration paragraph).
A4 Reset parameters 0 = Disabled / 1 = Enabled
Caution! If necessary, you can restore the default parameters with the following function:
Default settings reset operation and run calibration deletion.
Motor test and calibration menu
