Page 35 - Manual code: 119DW01EN vers. 5 2016/05 © CAME S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.A.
LED CONTROL BOARD (FA001) INDICATIONS
The CAME logo is always on.
FAST switch-on of the blue LED UPWARDS, indicating that the leaves are opening.
SLOW switch-on of the blue LED UPWARDS, indicating that the leaves are slowing down during
opening.
FAST switch-on of the blue LED DOWNWARDS, indicating that the leaves are closing.
SLOW switch-on of the blue LED DOWNWARDS, indicating that the leaves are slowing down during
closing.
