Page 24 - Manual FA01625-EN - 02/2023 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Automatic closure
Set the time before automatic closure is activated, once the opening travel end point has been reached.
The function does not work if any of the safety devices are triggered when an obstacle is detected, after a complete stop, during a power outage or if there is an
error.
F19
Automatic closure
0 =Deactivated (Default)
From 1 to 180 seconds
Pre-flashing time
Set the time for which the beacon is activated before each manoeuvre.
F21 Pre-flashing time 0 =Deactivated (Default)
1 to 10 seconds
Operating time
Set the gearmotor working time during opening and closing.
F22 Operating time 5 to 120 seconds (default 20 seconds)
Courtesy time
Set the lighting device operation time.
F25 Courtesy time 60 to 180 seconds (Default 180 seconds)
Opening and closing speed
Set the opening and closing speed.
For booms complete with accessories (swing rest and/or skirt), reduce the speed.
F28 Opening and closing speed MIN = minimum speed
MED = average speed
MAX = maximum speed
XMA = maximum speed for boom <3m
Slow-down speed
Set the slowdown speed.
F30 Slow-down speed MIN = minimum slowdown speed (Default)
MED = average slowdown speed
MIN = maximum slowdown speed
Calibration speed
Set the travel self-learning speed (percentage of maximum speed) and first manoeuvre speed
F33 Calibration speed 20% to 30%
Travel sensitivity
Adjust the obstruction detection sensitivity during boom travel.
F34 Travel sensitivity 10% to 100% (Default 100%) - 10% = maximum sensitivity - 100% = minimum sensitivity
