Page 25 - Manual FA01625-EN - 02/2023 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Slowdown sensitivity
Adjust the obstacle-detection sensitivity level during slowdown.
F35 Slowdown sensitivity 10% to 100% (Default 98%) - 10% = maximum sensitivity - 100% = minimum sensitivity
RSE
Configure the function to be performed by the card inserted in the RSE1 connector.
F49 RSE 0 =Deactivated (Default)
1 = Paired
2 = Compass
3 = CRP/CAME KEY
Save data
Save user data, timings and configurations to the memory device (memory roll or USB key).
F50 Save data 0 =Deactivated (Default)
1 = Activated
Read data
Upload user data, timings and configurations from the memory device (memory roll or USB key).
F51 Read data 0 =Deactivated (Default)
1 = Activated
Transferring MASTER-SLAVE parameters
Enable the sharing of parameters programmed on the Master barrier with the Slave barrier.
This only appears if the F49 function is set to Paired or Alternate.
F52 Transferring MASTER-SLAVE
parameters
0 =Deactivated (Default)
1 = Activated
CRP address
Assign a unique identification code (CRP address) to the control board. It is used where there are multiple operators connected via CRP.
F56 CRP address from 1 to 255
Sleep mode
This reduces the consumption of the photocells when they are in standby.
F60 Sleep mode 0 =Deactivated (Default)
1 = Activated
Pre-flashing
Choose the type of manoeuvre that activates the flashing beacon in advance.
Set how much earlier the flashing beacon is activated under the function [Pre-flashing time].
F61 Pre-flashing 0 = when opening and closing (Default)
1 = only when closing
2 = only when opening
