TRANSMITTER ENCODING
B
TOP QUARTZ
STANDARD ENCODING PROCEDURE
T262L/M-T264L/M-T2622M
T302L/M-T304L/M-T3022M
1.assign a code (also on file)
2.connect encoding jumper J
3.register code
4.disconnect jumper J
P1 P2
P3 P4
P1=CH1 - P2=CH2
P3=CH3 - P4=CH4
J
T264L/M - T304L/M
The first encoding operation must be carried out
whilst keeping the jumpers positioned for
channels 1 and 2 as per fig. A; see fig. B for any
subsequent settings on different channels.
T262L/M - T302L/M
P1 P2
J
P1=CH1
P2=CH2
fig. A
fig. B
P1=CH1 - P2=CH4
P1=CH1 - P2=CH3
P1=CH3 - P2=CH2
P1=CH3 - P2=CH4
P1 P2
T2622M - T3022M
2° code
ON
OFF
P1
P2
P3=CH1
P4=CH2
J
1° code
P1=CH1
P2=CH2
J
Press P1 or P2 in sequence in order to register
the code; at the tenth pulse, a double beep will
confirm that registration has occurred
2.
J
ON
OFF
P1
P2
code
1.
4.
J
3.
P1=OFF
P2=ON

CAME GARD series Specifications

General

Protection Rating	IP54
Input Voltage	230 V AC
Power Supply	230V AC
Motor Power	300W
Output Voltage	24V DC
Maximum Current	5A
Operating Temperature	-20°C to +55°C
