- pag. - pag.
- pag. - pag.
- pag.
1111
1111
11
- english - - english -
- english - - english -
- english -
AF
ADJUSTMENTS
ZL37B CONTROL PANEL
AF BOARD INSERTION
PROCEDURE
A. insertan AF card **.
B. encode transmitter/s.
C. store code in the motherboard.
TOP TAM
A
The AF board should ALWAYS be inserted when the
power is off because the motherboard only recognises it
when it is powered.
MOTHERBOARD
"AF" BOARD
PROGRAMMING THE REMOTE CONTROL
REGULACI
Ó
N TRIMMERS
EINTELLUNG TRIMMERS
R
É
GLAGE TRIMMERS
TRIMMERS ADJUSTMENT
REGOLAZIONE TRIMMERS
SENS.
T.C.A.
Trimmer SENS.
= Adjustment of amperometric sensitivity min./max.
Trimmer T.C.A.
= Adjustment automatic closing time from a minimun of 0 seconds to a maximum of 120
seconds.
2
1 345678910
0
Rall.
Vel.
74
(**) On AM transmitters operating at 433.92 MHz (TOP and
TAM series), position the jumper connection on circuit card
AF43S as shown on the sheet.
Frequency / MHz Radiofrequency board Transmi tte r
FM 26.995 AF130
TFM
FM 30.900 AF150
AM 26.995 AF26
TOP
AM 30.900 AF30
AM 433.92
AF43S / AF43SM TAM / TOP
AF43SR ATOMO
