CAME OPS001 - Dimensions (MM); Standard Installation

117
211
349
160
300
170
298
5
1
10
2
2
3
6
6
4
7
8
9
7
p. 6 - Manual FA01084-EN - 02/2018 - © CAME S.p.A. - "Translated original instructions"
DIMENSIONS (MM)
STANDARD INSTALLATION
1. Operator
2. Limit-switch fins
3. Rack
4. Key-switch selector
5. Flashing light
6. Photocells
7. Mechanical gate stop
8. Transmitter
9. Slide guides
10. Junction pit
