CAME PST001 User Manual

11
1
7
5
2
1
6
5
8
9
4
4
8
3
10
12
13
14
1200
950
750
250
195
ø 40
850
Pag.
3
-
Manual code
:
119G3040
119G3040 ver.
1.5
1.5 09/2010
© CAME cancelli automatici s.p.a. -
The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
4.4 Dimensions
4.3 Description of parts
Legs1.
Tripod2.
Steel body3.
Casing4.
Casing cover5.
Upper cover6.
Traffic-light with display7.
Transponder8.
Status display9.
Mechanism10.
Control panel11.
Cover lock12.
Screws and washers for fixing the legs13.
Screws for fixing the casing14.
