KEY
This symbol shows which parts to read carefully.
⚠
This symbol shows which parts describe safety issues.
☞
This symbol shows which parts to tell users about.
The measurements, unless otherwise stated, are in millimeters.
DESCRIPTION
Operator featuring a control panel with encoder for sectional and overhead garage doors.
Intended use
The VER06DES / VER08DES operators are designed to power overhead garage and sectional doors for homes and
apartment blocks.
Do not install of use this device in any way, except as specifi ed in this manual.
Limits to use
Type VER06DES VER08DES
Door's max. surface area (m
2
) 9 series 12 series
Counter-weighted overhead door's max. weight (m) 2.40 series
Maximum height of spring-balanced overhead doors (m) 3.25 series
Maximum height of sectional doors (m) 3.20 series
Technical data
Type VER06DES VER08DES
Protection rating (IP)
20 series
Power supply (V - 50/60 Hz) 230 AC
Motor power supply (V) 24 DC
Stand-by consumption (W) 4.5 series 6.5 series
Maximum power of the accessories (W) 20 series
Maximum power (W) 90 series 150 series
Maneuvering speed (m/min) 6.5 series 8 series
Traction force (N) 600 series 800 series
Acoustic pressure LpA (dBA) ≤70
Cycles/hour 10 series
Operating temperature (°C) -20 to +55
Apparatus class II
Weight (kg) 4.9 series 5.1 series
