CAME VER10 - Page 5

212140
400
3020 ÷ 4020
38
①
②
③
④
⑥
⑤
⑦
⑧
⑨
⑪
⑩
⑦
①
②
③
④
⑤
p.
5
5 - Manual
FA00045-EN
FA00045-EN v.
2
2 - 09/2016- © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
Description of parts
1. Cover
2. Gearmotor
3. Transformer
4. Control board
5. Transmission arm for the VER10*
6. Transmission arm for the VER12*
7. Door fastening brace
8. Guide fastening brace
9. Ceiling fastening brace
10. Cable gland
11. Fastening screws
☞(*) Only for sectional doors.
Dimensions
Description of the traction guide
1. Guide
2. Chain or belt
3. Traction assembly with release lever
4. Mechanical stop
5. Support rods
