CAME Z Series Installation Manual

Pag.
6
6 - Manual code:
319T98EN
319T98EN ver.
2.0
2.0 11/2012 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
24V a.c 25W Max. output terminal for flashing light (when moving)
24V D.C. Motor
230 V a.c. 50-60 Hz Power supply
Encode connection (to connect the automated device to the control board: use a type 2402C
22AWG shielded cable max. 10 m)
12 V 12 V
6.2 Electrical connections
M
+
-
+E
-
E
E
-
+E
+ E
-
-
Battery Battery
BN1 battery-charger card
++--
