Cameron NUFLO Scanner 2000 microEFM - Page 11

11
Scanner
®
2000 microEFM Section 1
MVT adapter
(NACE-compliant MVT available)
Multi-variable transmitter
High pressure/low pressure
port indicator
Integral vent plugs
LCD / keypad
Mount for pole-mount hardware
Ground screw
Conduit plug
Enclosure lid
(remove to access keypad)
Figure 1.1—Scanner 2000 microEFM with integral MVT; MVTs are available with bottom ports (shown) or side
ports
LCD / keypad
CSA-approved
3/4 in. to 1 in. adapter
CSA-approved
union (connects directly
to the turbine meter)
LCD / keypad
Mount for pole-mount hardware
Ground screw
Conduit plug
Enclosure lid
(remove to access keypad)
Figure 1.2—Scanner 2000 microEFM for direct connection to a turbine meter (CSA-approved)
