Appendix G. CR10X Programming
Example
Although this example is for the CR10X, the CR23X is programmed similarly.
;{CR10X}
;
;
;
*Table 1 Program
01: 900 Execution Interval (seconds)
1: Do (P86)
1: 42 Set Port 2 High
2: Beginning of Loop (P87)
1: 0000 Delay
2: 16 Loop Count
3: Do (P86)
1: 73 Pulse Port 3
4: Excitation with Delay (P22)
1: 1 Ex Channel
2: 0000 Delay W/Ex (0.01 sec units)
3: 10 Delay After Ex (0.01 sec units)
4: 0000 mV Excitation
5: SDI-12 Recorder (P105)
1: 0 SDI-12 Address
2: 1 Start Measurement (aM1!)
3: 1 Port
4: 91 Loc [ VW ]
5: 1.0 Multiplier
6: 0.0 Offset
6: Z=X (P31) ;Write Freq to inlocs 1-16
1: 91 X Loc [ VW ]
2: 1 -- Z Loc [ Freq_1 ]
7: Z=X (P31) ;Write Amp to inlocs 17-32
1: 92 X Loc [ Amplitude ]
2: 17 -- Z Loc [ Amp_1 ]
8: Z=X (P31) ;Write Signal to Noise ratio to inlocs 33-48
1: 93 X Loc [ Sig2Noise ]
2: 3 -- Z Loc [ S2Noise_1 ]
9: Z=X (P31) ;Write Frequency of Noise to inlocs 49-64
1: 94 X Loc [ NoiseFreq ]
2: 49 -- Z Loc [ NsFreq_1 ]
