* Model Dependent
Network Type 3 Phase - 3 Wire / 3 Phase - 4 Wire
Aux-Supply 140 - 265V AC / DC, 50 / 60Hz, 12VA
Sensing/Measurement True RMS
Operating Voltage Voltage input : L-N or L-L
Range : 50 to 500V AC; 50/60 Hz
Operating Current 40mA - 7.5A ( /5A Current Transformer)
Relay Output Contact Type : N/O, Rating: 5A @250V AC,1250VA
(*)
Capacitor Steps 12 Steps (Max)
Power Consumption <0.2VA (Current Circuit)
<5VA (Voltage Circuit)
Target Cos setting 0.80 Lag - 1.00 - 0.8 LeadØ
CT Ratio Configurable (Max 9999)
Compliance / Standard IEC 61000
0 0
Operating Temperature Range 0 C to +55 C
0 0
Storage Temperature Range -10 C to +70 C
Humidity Range 5% to 95% non condensing
Installation Panel mounting & fitted by side screw
clamp
Dimension (H x W x D) (144 x 144 x 80) mm
Packing Weight 900 gms (Approx)
Technical Data
C/k = Power Of First Capacitor in kVAr (Q) / Current Transformer Ratio (CT Ratio)
C/k Ratio
This setting is a threshold value for switching on/off capacitors steps. It is calculated
based on the smallest size capacitor.
13
