Programmable Parameters
Basic Setting
Table-1
Parameters Display Setting Range Step Unit Default
Min Max Size
(1)
Target Cos CoS 0.80 -0.80 0.01 - 1.00Ø
(2)
C/K Ratio C.h 0.03 02.00 0.01 - 0.04
External CT Ratio CTR 1 9999 1 - 1
Bank switch ON delay t.on 1 9999 1 Sec 5
(3)
Switching program selection PEmS PE 1 PE 9 - - PE 1
(1)
Note : Target Cos setting 0.80 to -0.80 means 0.80 (lagging) to 0.80 (leading)Ø
(1)
Note : Phase Angle should be set as per the voltage and current connection
shown in connection scheme.
(2)
Model Dependent.
(2)
Refer C/K Ratio section to set proper value.
(3)
Switching program determines the power (kVAr) ratio sequence of the capacitor
Bank steps connected.
(A) Common Parameters
Advance Setting
Table-2
-
Parameters Display Setting Range Step Unit Default
Min Max Size
Nominal Voltage UnoN 150 435 1 V 415
(1)
Phase Angle AnEL 0 330 30 Degree 90
Bank switch OFF delay T_of 1 9999 1 Sec 10
(2)
No. of Capacitor Bank used Step 1 12 1 - 12
0
Fan ON Temperature F-on 5 100 1 C 45
0
Fan OFF Temperature F-of 5 90 1 C 40
PE6 1:1:2:2:2
PE7 1:1:2:4:4
PE8 1:2:3:4:4
Pe9 Linear
(Any combination)
Pe1 1:1:1:1:1
PE2 1:2:2:2:2
PE3 1:2:4:4:4
PE4 1:2:4:8:8
Pe5 1:2:3:3:3
08
