C&S CSPF-100 - Alarm and Protection Settings; Alarm Parameters Configuration

Table-3
(B) Alarm Parameters
Parameters Display Setting Range Step Unit Default
Min Max Size
(1)
Over Voltage setting oURU 150 490 1 V 456
Over Voltage Alarm delay DELY 1 999 1 Sec 5
(2)
Capacitor Bank Trip
selection on Over voltage CAP OFF ON - - OFF
(1)
3
Over current Setting oURC 50 150 1 %%In OFF
Over current Alarm Delay DELY 1 999 1 Sec 5
(2)
Capacitor Bank Trip
selection on Over current CAP OFF ON - - OFF
(1)
3
Under current Setting vNDC 1 90 1 %%In OFF
Under current Alarm delay DELY 1 999 1 Sec 5
(2)
Capacitor Bank Trip
selection on Under current CAP OFF ON - - OFF
(1)
Over compensation oCo 1 600 1 Sec 5
(1)
Under compensation vCo 1 600 1 Sec 5
(1)
0
Temp High Set T-HI 10 120 1 C 55
0
Temp Low Set T-Lo 10 120 1 C 50
Temp High Alarm Delay DELY 1 999 1 Sec 300
Capacitor Bank Trip selection
(2)
on high Temperature CAP OFF ON - - OFF
Note : 1. Alarm settings will have disable (OFF) option
2. This alarm setting has corresponding capacitor bank trip selection (CAP)
If CAP is selected to ON, capacitor bank will be switched OFF on
occurrence of that particular fault / alarm.
3. In = Rated Current (5A)
09
