Candy OCGF12B - Oven Door Cleaning and Reassembly

35
Cleaning And Mounting Oven Door
Reversely perform respectively what you did while opening door to reinstall
oven door back.
Figure 23
Figure 23.1 Figure 23.2 Figure 24.1 Figure 24.2
Figure 24
Open the door fully
by pulling the
oven door toward
yourself. Then
perform unlock
operation by pulling
the hinge lock
upwards with the
aid of screwdriver
as indicated in
gure 23.1.
Set the hinge lock
to the widest angle
as in gure 23.2.
Adjust both hinges
connecting oven
door to the oven to
the same position.
Later, close the
opened oven door
so that it will be
in a position to
contact with
hinge lock as in
gure 24.1.
For easier removal
of oven door, when
it comes close to
closed position,
hold the cover
with two hands as
in gure 24.2
and pull upwards.
