Canon DADF-M1 - Height

Chapter 4
4-29
4.3.1.6 Height
0003-1849
1) With the machine closed, check to see if the height adjusting rolls [1] found at the left
rear and front are in contact with the reading glass [2].
F-4-34
Memo:
To facilitate the work, try executing the following to turn on the scanning lamp using the
host machine's service mode: COPIER>FUNCTION>MISC-R>SCANLAMP.
[1]
[2]
