Nomenclature
<o> AF mode
selection/Drive mode
selection button (p.78/85)
<m>
ISO speed
setting/
Flash exposure
compensation button
(p.57/103)
<U> LCD panel
illumination button
(p.99)
<6> Main Dial
(p.36)
Shutter button
(p.35)
Self-timer lamp
(p.86)
Remote control
sensor (p.102)
Grip (Battery
compartment)
DC coupler cord
hole (p.216)
Mirror (p.101,169)
Contacts (p.13)
Lens mount
Lens lock pin
Depth-of-field preview
button (p.93)
Lens release button (p.32)
Date/time battery
(p.217)
Microphone
(p.128)
Terminal cover
Strap mount
(p.23)
Mode Dial (p.20)
<V> Focal plane mark
Hot shoe (p.103)
Flash-sync contacts (p.103)
EF lens mount index (p.31)
LCD panel (p.18)
<n>
Metering mode selection
/
White balance selection button (p.95/65)
PC terminal (p.104)
Digital terminal (p.172,185)
Remote control terminal (N3 type) (p.100)
HDMI mini OUT terminal (p.158)
Audio/video OUT terminal (p.157)
External microphone IN terminal (p.140)
Body cap (p.31)
