Adjusting the Printhead
2. Press the Menu button to display MAIN MENU .
3. Press ▲ or ▼ to select Adjust Printer , and then press the ► button.
4. Press ▲ or ▼ to select Auto Head Adj. , and then press the ► button.
5. Press ▲ or ▼ to select Advanced Adj. , and then press the ► button.
6. Press ▲ or ▼ to select Y es , and then press the OK button.
A test pattern is printed for printhead adjustment.
After reading the pattern, the printer automatically adjusts the Printhead alignment.
Note
• If paper is fed automatically and no roll is loaded, select the media source and click the OK button.
Adjustments for Better Print Quality 573
