T-6-26
T-6-27
21 H1-E-DATA-9-EV IN Even head data signal 9(E)
22 H1-E-DATA-8-EV IN Even head data signal 8(E)
23 /H1-D-HE-7 IN Head heat enable signal 7(D)
24 H1-D-DATA-7-EV IN Even head data signal 7(D)
25 H1-D-DATA-6-EV IN Even head data signal 6(D)
26 /H1-D-HE-6 IN Head heat enable signal 6(D)
27 H1-D-DATA-6-OD IN Odd head data signal 6(D)
28 H1-D-DATA-7-OD IN Odd head data signal 7(D)
29 H1_CLK IN Head clock signal
30 H1-C-DATA-5-OD IN Odd head data signal 5(C)
31 /H1-C-HE-5 IN Head heat enable signal 5(C)
32 H1-C-DATA-5-EV IN Even head data signal 5(C)
33 /H1_LT IN Head latch signal
34 H1-C-DATA-4-EV IN Even head data signal 4(C)
35 /H1-B-HE-3 IN Head heat enable signal 3(B)
36 H1-B-DATA-3-EV IN Even head data signal 3(B)
37 H1-B-DATA-2-EV IN Even head data signal 2(B)
38 /H1-A-HE-1 IN Head heat enable signal 1(A)
39 H1-A-DATA-1-EV IN Even head data signal 1(A)
40 H1-A-DATA-0-EV IN Even head data signal 0(A)
41 /H1-A-HE-0 IN Head heat enable signal 0(A)
42 H1-A-DATA-0-OD IN Odd head data signal 0(A)
43 H1-A-DATA-1-OD IN Odd head data signal 1(A)
44 /H1-B-HE-2 IN Head heat enable signal 2(B)
45 H1-B-DATA-2-OD IN Odd head data signal 2(B)
46 H1-B-DATA-3-OD IN Odd head data signal 3(B)
47 /H1-C-HE-4 IN Head heat enable signal 4(C)
48 H1-C-DATA-4-OD IN Odd head data signal 4(C)
49 MLT_SNS_1IN OUT Multi sensor signal 1
50 MLT_SNS_2IN OUT Multi sensor signal 2
J201
Pin Number Signal name IN/OUT Function
1 PWLED1 OUT Multi sensor LED1 drive signal
2 PWLED2 OUT Multi sensor LED2 drive signal
3 PWLED3 OUT Multi sensor LED3 drive signal
4 PWLED4 OUT Multi sensor LED4 drive signal
5 GND - GND
6 MLT_SNS_1 IN Multi sensor signal 1
7 +5V OUT Power supply (+5V)
8 MLT_SNS_2 IN Multi sensor signal 2
J601
Pin Number Signal name IN/OUT Function
1 VH2 OUT Power supply
2 VH2 OUT Power supply
3 VH2 OUT Power supply
4 VHT12 OUT Head transistor drive power supply
5 H1-F-DATA-10-EV OUT Even head data signal 10(F)
6 IO_ASIC_SDA IN/OUT Head ROM control signal (data)
7 IO_ASIC_SCL IN/OUT Head ROM control signal (clock)
8 H3V_1 OUT Power supply (+3V)
9 H1-C-DIA1 IN Head DI sensor signal 1(C)
10 /H1-A-HE-1 OUT Head heat enable signal 1(A)
11 VH1 OUT Power supply
12 VH1 OUT Power supply
13 VH1 OUT Power supply
14 VH2 OUT Power supply
15 VH2 OUT Power supply
16 H1-E-DATA-9-OD OUT Odd head data signal 9(E)
17 /H1-F-HE-11 OUT Head heat enable signal 11(F)
18 H1-E-DIA1 IN Head DI sensor signal 1(E)
19 H1-D-DIA1 IN Head DI sensor signal 1(D)
20 H3V_1 OUT Power supply (+3V)
J102
Pin Number Signal name IN/OUT Function
