Canon iPF700 Series - Details of Service Mode

Chapter 7
7-5
F-7-5
7.1.3 Details of Service Mode
0013-7791
This section provides details of the Service mode menus.
a. DISPLAY
Displays and prints the printer information.
(1) PRINF INF
Prints adjustment values in the User menu an all of DISPLAY and COUNTER parameters on A4-size or lager paper.
When a roll media is used,the layout is optimized according to the media width in order to save paper.
(2) SYSTEM
Displays the printer information shown below.
T-7-1
(3) HEAD
Displays the following EEPROM information in the printhead.
T-7-2
(4) INK
Displays the numbers of days passed since installation of the following ink tanks.
If any ink tank that does not allow the printer to count the number of days passed is installed,an error message is displayed.
T-7-3
(5) WARNING
Displays the warning history(up to 20 events). The newest event has the smallest history number.
(6) ERROR
Displays the error history(up to 20 events). The newest event has the smallest history number.
Display Description Unit
S/N Serial number of printer -
TYPE Type setting on main controller PCB
* iPF700 is represented by 36.
-
LF TYPE Feed roller type 0 or 1
TMP Ambient temperature C
SIZE LF Detected size of loaded media (feed direction)
0 is always detected for the roll media.
mm/inch
SIZE CR Detected size of loaded media (carriage direction) mm/inch
Display Description
S/N Serial number of printhead
LOT Lot number of printhead
Display Description Unit
BK Number of days passed since the BK ink tank was installed Day(s)
MBK Number of days passed since the MBK ink tank was installed Day(s)
MBK2 Number of days passed since the MBK2 ink tank was installed Day(s)
C Number of days passed since the C ink tank was installed Day(s)
M Number of days passed since the M ink tank was installed Day(s)
Y Number of days passed since the Y ink tank was installed Day(s)
SETTING
Pth
ON
OFF
RTC
DATE
TIME
INITIALIZE
WARNING
ERROR
ADJUST
W-INK
CARRIAGE
PURGE
INK-USE CNT
CUTTER-CHG CNT
W-INK CHG CNT
HEAD-CHG CNT
PARTS-CHG CNT
PARTS A1
PARTS B1
PARTS D
PARTS M1
PARTS COUNTER
PARTS A1
PARTS B1
PARTS D
PARTS M1
(COUNTER)
