7.1 Service Mode
7.1.1 Service Mode
0013-7777
a. How to enter the Service mode
Enter the Service mode following the procedure below.
(1) Turn off the printer.
(2) Turn on the printer while holding down the [Paper Source]key and [Informarion]key.
*Keep pressing the above buttons until "Initializing"appears on the display.
(3) "S" is displayed in the upper right corner of the display showing the version.
(4) After display of "Online",pressing the [Menu]key displays the SERVICE MODE top menu and the MESSAGE LED flashies.
*The Service mode is added to the options in the Main menu. The Service mode can be entered even in the error status(when an error message is shown on the
display)by turning the power off and then using the above key operation.
b. How to exit the Service mode
Turn off the printer.
c. Key operation in the service mode
-Selecting menus and paremeters:[ ] or [ ] key
-Going to the next lower-level menu:[ ] key
-Going to the next higher-level menu:[ ] key
-Determining a selected menu or parameter:[OK] key
7.1.2 Service Mode Map
0013-7787
The hierarchy of menus and parameters in the Service mode is shown below.
F-7-1
DISPLAY
YES
NO
S/N
TYPE
LF TYPE
Test Print
TMP
SIZE LF
SIZE CR
S/N
LOT
1
20
1
20
WARING
ERROR
INK CHECK
System Setup
SERVICE MODE
PRINT INF
SYSTEM
HEAD
INK
(I/O DISPLAY)
BK
MBK
C
M
Y
MBK2
C,M,Y,MBK,MBK2,BK
To Next Page
