1.7 Safety and Precautions
1.7.1 Safety Precautions
1.7.1.1 Moving parts of the printer
0013-5153
Be careful not to get your hairs, clothing, accessories or any other objects caught in the moving parts of the printer.
The moving parts of the printer include the carriage unit, carriage belt, ink tube, flexible cable and feed motor driven by the carriage motor and the feed and pinch
rollers driven by the feed motor and the purge unit driven by the purge motor.
To assure safety, the printer locks the top cover from opening while it is printing. When the top cover is opened while the printer is in online or offline mode, the
driving power to the carriage and feed motors is shut down.
F-1-23
Carriage unit
purge unit
Carriage motor
Carriage belt
Pinch roller
Feed roller
Ink tube
Flexible cable
Feed motor
Feed unit
