Canon iR3245 Series User Manual

Chapter 16
16-10
* When the machine starts up for the first time after its HDD has been formatted, it may take longer than usual to complete the startup session.
[Remedy]
T-16-10
16.1.8 E604 to E748 (Main Controller, DC Controller)
0019-7876
iR3225 / iR3225N / iR3235 / iR3235N / iR3245 / iR3245N
T-16-11
FF 0 Not
identified
Entire HDD (check on faulty sector and
recovery)
----
YY Description Action
*1
03
The ongoing write operation is
interrupted (at start-up).
- Set the partition number in question for CHK-TYPE, and execute HD-CLEAR; then, turn off and then back
on the power.
- Enter CHK-TYPE in question (for the partition), and execute HD-CLEAR; then, turn off and then back on
the power.
*2
- Ask the user to download the address book data using a remote UI.
- Set the partition number in question for CHK-TYPE, and execute HD-CLEAR; then, turn off and then back
on the power.
- Replace the HDD, and reinstall the system software.
*3
- Set CHK-TYPE=0, and execute HD-CHECK; then, turn off and then back on the power.
- Replace the HDD, and reinstall the system software.
*4
- Set CHK-TYPE=0, and execute HD-CHECK; then, turn off and then back on the power.
- Set CHK-TYPE=1, 2, 3, 5, and execute HD-CLEAR; then, turn off and then back on the power.
*5
05 A file system error has occurred.
- Enter CHK-TYPE in question (for the partition), and execute HD-CLEAR; then, turn off and then back on
the power.
- Replace the HDD, and reinstall the system software.
*6
The machine is designed so that execution of HD-CLEAR is not possible in service mode (so as to prevent
loss of information, e.g., address book, filter information).
- Ask the user to download the address book data using a remote UI.
- Replace the HDD, and reinstall the system software.
*7
- Set CHK-TYPE=1, 2, 3, 5, and execute HD-CLEAR; then, turn off and then back on the power.
- Replace the HDD, and reinstall the system software.
*8
- Replace the HDD, and reinstall the system software.
*9
00
01
02
04
The HDD has poor contact, or a
system error has occurred.
- Check the cable and the power cord.
- Replace the HDD, and reinstall the system software.
*10
11
21
The HDD has poor contact.
- Check the cable and the power cord.
- Replace the HDD, and reinstall the system software.
*11
13
25
The ongoing write operation has
been interrupted.
There is a strong possibility of damage in the file data (e.g., Box) stored on the HDD.
- Set the partition number in question for CHK-TYPE, and execute HD-CHECK; then, turn off and back on
the power.
- Set the partition number in question for CHK-TYPE, and execute HD-CLEAR; then, turn off and back on
the power.
(In the case of BOOTDEV, BOOTDEV2 or APL_SEND, execute reformatting using the SST, and reinstall
the system software.)
- Replace the HDD, and reinstall the system software.
*12
10
12
14
22
23
24
A system error or a packet error
has been detected.
- Replace the HDD, and reinstall the system software.
- HD-CLEAR
When you have executed HD-CLEAR, all contents of the partition in question (files, sub directories) will be lost.
The actual formatting will take place when the machine is started up after it has been turned off upon execution of HD-CLEAN.
At this time, the Startup screen shows a progress bar, its edge reaching the end in about 5 min. Be sure not to turn off the power while the progress bar is moving.
- HD-CHECK
If the power is cut while data is being written to the HDD, the occurrence of a write-suspended sector is a possibility. When HD-CHECK is run on such a sector,
repairs will be made, but all data in the sector will be lost. A write-suspended sector may be repaired only by HDD-CHECK (0); if not TYPE-TYPE=0, the task will
be limited to an FS level check.
- Replacing the HDD
1. Turn OFF the main power.
2. Connect a new HDD.
3. Start the host machine in safe mode.
4. Download System, RUI and Lang with service support tool.
5. Turn OFF/ON the power.
Code Cause Remedy
E604 The image memory is faulty or is inadequate.
XX CHK
-
TYP
E
Partition in
question
Description Typical item
deleted
HDD formatting by
HD-CLEAR
Normal mode +
HDD formatting
with SST
Safe mode + HDD
formatting with SST
