Canon iR3245 Series User Manual

Chapter 17
17-26
17.2.1.8 COPIER > DISPLAY > CCD
0019-9276
iR3225 / iR3225N / iR3235 / iR3235N / iR3245 / iR3245N
T-17-6
COPIER > DISPLAY > CCD
Item Level Description
TARGET-B 2 Title Target value of shading for blue
Purpose When replacing the reader controller PCB, if the scanned image has some failure, check the target
value of shading for blue.
Note If the machine continues to display 0 (minimum) or FFFF (maximum), there may be some problem on
reader controller PCB.
Displays, settings and
adjustment ranges
-
Unit -
Appropriate guideline 1 to 2047
Related service modes -
Additional description and
notes
-
TARGET-G 2 Title Target value of shading for green
Purpose When replacing the reader controller PCB, if the scanned image has some failure, check the target
value of shading for green.
Note If the machine continues to display 0 (minimum) or FFFF (maximum), there may be some problem on
reader controller PCB.
Displays, settings and
adjustment ranges
-
Unit -
Appropriate guideline 1 to 2047
Related service modes -
Additional description and
notes
-
TARGET-R 2 Title Target value of shading for red
Purpose When replacing the reader controller PCB, if the scanned image has some failure, check the target
value of shading for red.
Note If the machine continues to display 0 (minimum) or FFFF (maximum), there may be some problem on
reader controller PCB.
Displays, settings and
adjustment ranges
-
Unit -
Appropriate guideline 1 to 2047
Related service modes -
Additional description and
notes
-
OFST-B 2 Title Adjustment value of offset level on CCD (blue)
Purpose To judge if this adjustment value is correct when an image fault attributed to CCD occurs.
Note -
Displays, settings and
adjustment ranges
-
Unit -
Appropriate guideline 0 to 255
Related service modes -
Additional description and
notes
-
OFST-G 2 Title Adjustment value of offset level on CCD (green)
Purpose To judge if this adjustment value is correct when an image fault attributed to CCD occurs.
Note -
Displays, settings and
adjustment ranges
-
Unit -
Appropriate guideline 0 to 255
Related service modes -
Additional description and
notes
-
OFST-R 2 Title Adjustment value of offset level on CCD (red)
Purpose To judge if this adjustment value is correct when an image fault attributed to CCD occurs.
Note -
Displays, settings and
adjustment ranges
-
Unit -
Appropriate guideline 0 to 255
Related service modes -
Additional description and
notes
-

Canon iR3245 Series Specifications

General

Print Speed	Up to 45 ppm (A4)
Resolution	1200 x 1200 dpi
First Copy Time	3.9 seconds
Maximum Copy Size	A3
Duplex Printing	Automatic
Scanning Resolution	600 x 600 dpi
Interface	USB 2.0, Ethernet
Power Consumption	1.5 kW (Max)
Functions	Copy, Print, Scan
Warm-Up Time	30 seconds
Paper Capacity Standard	550 sheets
Network Connectivity	Ethernet (100Base-TX/10Base-T)
Memory	512 MB (Standard)
Hard Disk Drive	Optional 40 GB
Operation Panel	5.7-inch QVGA
Paper Sizes	A3, A4, A5, B4, B5
Paper Weights	64 to 128 gsm
PDL	PCL5e, PCL6, UFR II, PS3
Network Protocols	TCP/IP, IPX/SPX
